2ml Bottle Filter Sample Handling Filters
Product Description
The B&M® Vial Filter consists of an outer tube, a cap cushion and an inner cannula containing a 0.2 or 0.45 mm membrane at the bottom of the inner cannula. To work, the sample is placed in the outer tube, then the inner cannula is inserted into the outer tube and pushed downwards, allowing the filtrate to pass through the membrane from bottom to top and into the cartridge. Air escapes through a small hole in the top until a retaining ring seals the unit. When two parts are joined into one, they are compatible in size with the autosampler.
Filter Bottle Filter Outer Tube
2ml volume, made of high-purity medical grade polypropylene, insoluble in LC-MS after immersion in commonly used solvents, can be used repeatedly.
Filter bottle filter inner cannula
High purity medical grade polypropylene material, press cap design. White silicone rubber/red PTFE gasket is used for pre-opening; The lower membrane of the filter is made of nylon, mixed cellulose or PTFE material, etc., with a pore size of 0.22μm and 0.45um.
Product Features
Fast: Only 2 steps, instant and easy filtration of the sample before injection.
Versatile: Suitable for Waters, Aqliqent, Shimadzu and other common liquid chromatographs.
High Quality: Made of high-purity medical grade polypropylene, insoluble.
Cleanliness: Manufactured in a class 100,000 clean room.
Order Details
| Product Number | Brand Name | norm | wrap |
| NY022N | 2ml Bottle Filter | 0.22um Nylon Hydrophilic Membrane | 100/carton |
| NY045N | 0.45um Nylon Hydrophilic Membrane | 100/carton | |
| PE022N | Hydrophilic Membrane PES 0.22um | 100/carton | |
| PE045N | Hydrophilic Membrane PES 0.45um | 100/carton | |
| PT022N | Hydrophilic Membrane PES 0.22um | 100/carton | |
| PT045N | Hydrophilic Membrane PES 0.45um | 100/carton | |
| PV022N | Hydrophilic Membrane PES 0.22um | 100/carton | |
| PV045N | Hydrophilic Membrane PES 0.45um | 100/carton | |
| Personalization | Personalization | 100/carton |
